Western blot analysis of beta Actin on HepG2 cell lysates with Rabbit anti-beta Actin antibody (HA601037) at different dilutions.
Lysates/proteins at 10 µg/Lane.
Predicted band size: 42 kDa
Observed band size: 42 kDa
Exposure time: 30 seconds;
12% SDS-PAGE gel.
Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601037) at different dilutions were used in 5% NFDM/TBST at room temperature for 2 hours.
-
Western blot analysis of beta Actin on NIH/3T3 cell lysates with Rabbit anti-beta Actin antibody (HA601037) at different dilutions.
Lysates/proteins at 10 µg/Lane.
Predicted band size: 42 kDa
Observed band size: 42 kDa
Exposure time: 30 seconds;
10% SDS-PAGE gel.
Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601037) at different dilutions were used in 5% NFDM/TBST at room temperature for 2 hours.
-
Western blot analysis of beta Actin on PC-12 cell lysates with Rabbit anti-beta Actin antibody (HA601037) at different dilutions.
Lysates/proteins at 10 µg/Lane.
Predicted band size: 42 kDa
Observed band size: 42 kDa
Exposure time: 30 seconds;
10% SDS-PAGE gel.
Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601037) at different dilutions were used in 5% NFDM/TBST at room temperature for 2 hours.
-
Western blot analysis of beta Actin on different lysates with Mouse anti-beta Actin antibody (HA601037) at 1/10,000 dilution.
Lane 1: THP-1 cell lysate
Lane 2: MCF-7 cell lysate
Lane 3: RH-35 cell lysate
Lane 4: L6 cell lysate
Lane 5: MEF cell lysate
Lane 6: HepG2 cell lysate
Lane 7: PC-12 cell lysate
Lane 8: NIH/3T3 cell lysate
Lane 9: RAW264.7 cell lysate
Lane 10: A549 cell lysate
Lane 11: PMVEC cell lysate
Lysates/proteins at 10 µg/Lane.
Predicted band size: 42 kDa
Observed band size: 42 kDa
Exposure time: 30 seconds;
10% SDS-PAGE gel.
Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601037) at 1/10,000 dilution was used in 5% NFDM/TBST at room temperature for 2 hours.
